Spherical roller bearing 23232 K – 160×290×104 mm
19 offers · 5 manufacturers · net prices from PLN 2,795.85 · dispatch in 2 working days
23232 K is a spherical roller bearing with a 160 mm bore, 290 mm outside diameter and 104 mm width, open design (no seals) – for externally lubricated arrangements with a tapered bore (K) for adapter sleeve mounting. The dimensions are standardised, so items from different manufacturers with the same clearance and sealing are interchangeable 1:1. All brands with current net prices are listed below.
- bore d
- 160 mm
- outside D
- 290 mm
- width B
- 104 mm
- sealing
- open
- mass
- 27.9 kg
- net price from
- PLN 2,795.85
Brands and prices 23232 K
Net price per piece, gross incl. 23% VAT. Selected items go into one enquiry – we reply within 24 h, with better prices for larger quantities.
| Brand | Manufacturer designation | Clearance | Net price | Availability | |
|---|---|---|---|---|---|
| FAG | 23232 K.E1TVPBtapered bore, taper 1:12, reinforced design E1 (FAG), polyamide window cage, ball centred (FAG) | CN | PLN 2,795.85PLN 3,438.90 gross | supplier stockdispatch in 2 working days | |
| FAG | 23232 K.E1TVPBC3tapered bore, taper 1:12, reinforced design E1 (FAG), polyamide window cage, ball centred (FAG) | C3 | PLN 2,889.00PLN 3,553.47 gross | supplier stockdispatch in 2 working days | |
| NSK | 23232 CKE4C3S11tapered bore, taper 1:12, reinforced design, higher load rating | CN | PLN 2,949.33PLN 3,627.68 gross | supplier stockdispatch in 2 working days | |
| NSK | 23232 CKE4S11tapered bore, taper 1:12, reinforced design, higher load rating | CN | PLN 2,949.33PLN 3,627.68 gross | supplier stockdispatch in 2 working days | |
| TIMKEN | 23232 KEJW33C3tapered bore, taper 1:12, pressed steel cage (Timken), lubrication groove and holes in the outer ring | C3 | PLN 2,986.68PLN 3,673.62 gross | supplier stockdispatch in 2 working days | |
| TIMKEN | 23232 KEJW33tapered bore, taper 1:12, pressed steel cage (Timken), lubrication groove and holes in the outer ring | CN | PLN 2,986.68PLN 3,673.62 gross | supplier stockdispatch in 2 working days | |
| FAG | 23232 K.E1AMtapered bore, taper 1:12, reinforced design E1 (FAG), machined brass cage | CN | PLN 3,004.50PLN 3,695.54 gross | supplier stockdispatch in 2 working days | |
| FAG | 23232-E1-XL-K-TVPB-C4reinforced design E1 (FAG), tapered bore, taper 1:12, polyamide window cage, ball centred (FAG) | C4 | PLN 3,033.56PLN 3,731.28 gross | supplier stockdispatch in 2 working days | |
| FAG | 23232 K.E1AMC3tapered bore, taper 1:12, reinforced design E1 (FAG), machined brass cage | C3 | PLN 3,104.67PLN 3,818.74 gross | supplier stockdispatch in 2 working days | |
| KOYO | 23232 RKW33C3tapered bore, taper 1:12, lubrication groove and holes in the outer ring | C3 | PLN 3,123.47PLN 3,841.87 gross | supplier stockdispatch in 2 working days | |
| KOYO | 23232 RKW33tapered bore, taper 1:12, lubrication groove and holes in the outer ring | CN | PLN 3,123.47PLN 3,841.87 gross | supplier stockdispatch in 2 working days | |
| NSK | 23232 CAMKE4C3S11machined brass cage CA, modified (SKF), tapered bore, taper 1:12, reinforced design, higher load rating | CN | PLN 3,140.45PLN 3,862.75 gross | supplier stockdispatch in 2 working days | |
| NSK | 23232 CAMKE4S11machined brass cage CA, modified (SKF), tapered bore, taper 1:12, reinforced design, higher load rating | CN | PLN 3,140.45PLN 3,862.75 gross | supplier stockdispatch in 2 working days | |
| KOYO | 23232 RHAKW33tapered bore, taper 1:12, lubrication groove and holes in the outer ring | CN | PLN 3,217.16PLN 3,957.11 gross | supplier stockdispatch in 2 working days | |
| KOYO | 23232 RHAKW33C3tapered bore, taper 1:12, lubrication groove and holes in the outer ring | C3 | PLN 3,217.16PLN 3,957.11 gross | supplier stockdispatch in 2 working days | |
| FAG | 23232-E1A-XL-K-M-C4reinforced design E1 (FAG), tapered bore, taper 1:12, machined brass cage | C4 | PLN 3,258.73PLN 4,008.24 gross | supplier stockdispatch in 2 working days | |
| SKF | 23232 K.CCW33tapered bore, taper 1:12, pressed steel window-type cage (SKF), lubrication groove and holes in the outer ring | CN | PLN 3,930.35PLN 4,834.33 gross | supplier stockdispatch in 2 working days | |
| SKF | 23232 K.CCC3W33tapered bore, taper 1:12, pressed steel window-type cage (SKF), lubrication groove and holes in the outer ring | C3 | PLN 4,033.75PLN 4,961.51 gross | supplier stockdispatch in 2 working days | |
| SKF | 23232 K.CCC4W33tapered bore, taper 1:12, pressed steel window-type cage (SKF), lubrication groove and holes in the outer ring | C4 | PLN 4,033.75PLN 4,961.51 gross | supplier stockdispatch in 2 working days |
Can't see your brand? Ask for an offer – we reply within 24 h.
Other versions of 23232
The same size in another design – open, shielded, tapered bore.
How manufacturers designate 23232 K
Each brand uses its own seal and design codes. The designations below describe the same bearing.
| Manufacturer | Designation | Sealing / design |
|---|---|---|
| FAG | 23232 K.E1TVPB | Open |
| NSK | 23232 CKE4C3S11 | Open |
| KOYO | 23232 RKW33C3 | Open |
| SKF | 23232 K.CCW33 | Open |
| TIMKEN | 23232 KEJW33C3 | Open |
Questions about 23232 K
What are the dimensions of bearing 23232 K?
Bore 160 mm, outside diameter 290 mm, width 104 mm. Standardised dimensions – the same for every manufacturer.
Are 23232 K bearings from different brands interchangeable?
Yes. 23232 K.E1TVPB FAG, 23232 CKE4C3S11 NSK, 23232 RKW33C3 KOYO, 23232 K.CCW33 SKF, 23232 KEJW33C3 TIMKEN are the same bearing under different manufacturers' designations. Match the clearance (e.g. C3) and the sealing.
How much does bearing 23232 K cost?
At Castomer from PLN 2,795.85 to PLN 4,033.75 net per piece depending on the manufacturer (FAG, NSK, KOYO, SKF, TIMKEN). Prices are updated from supplier warehouses; larger quantities get an individual offer.
What is the delivery time for 23232 K?
Dispatch in 2 working days from supplier warehouses in the EU. Availability is confirmed in the reply to your enquiry.
