Deep groove ball bearing 306 – 30×72×19 mm
3 offers · 1 manufacturer · net prices from PLN 159.02 · dispatch in 2 working days
306 is a deep groove ball bearing with a 30 mm bore, 72 mm outside diameter and 19 mm width, open design (no seals) – for externally lubricated arrangements. The dimensions are standardised, so items from different manufacturers with the same clearance and sealing are interchangeable 1:1. All brands with current net prices are listed below.
- bore d
- 30 mm
- outside D
- 72 mm
- width B
- 19 mm
- sealing
- open
- mass
- 0.37 kg
- net price from
- PLN 159.02
Brands and prices 306
Net price per piece, gross incl. 23% VAT. Selected items go into one enquiry – we reply within 24 h, with better prices for larger quantities.
| Brand | Manufacturer designation | Clearance | Net price | Availability | |
|---|---|---|---|---|---|
| SKF | 306 | CN | PLN 159.02PLN 195.59 gross | supplier stockdispatch in 2 working days | |
| SKF | 306 C3 | C3 | PLN 187.06PLN 230.08 gross | supplier stockdispatch in 2 working days |
▸Special designs 306 (1) – stainless steel, snap ring, manufacturer specials
| SKF | 306 NRsnap ring groove with snap ring | CN | PLN 182.89PLN 224.95 gross | supplier stockdispatch in 2 working days |
Can't see your brand? Ask for an offer – we reply within 24 h.
Other versions of 306
The same size in another design – open, shielded, tapered bore.
2RS, 2Z or C3 – which to choose?
2RS (two rubber seals) keeps dust and moisture out but limits speed. 2Z (metal shields) does not touch the ring, so it runs faster and cooler but protects less. 2RZ is the compromise – a non-contact seal.
Choose C3 clearance when the bearing runs hot (electric motors, fans) or with a tight shaft fit. Normal clearance CN is enough for ordinary applications.
The dimensions of 306 are identical for every manufacturer, so the items in the table are interchangeable – just match the clearance and sealing.
Questions about 306
What are the dimensions of bearing 306?
Bore 30 mm, outside diameter 72 mm, width 19 mm. Standardised dimensions – the same for every manufacturer.
How much does bearing 306 cost?
At Castomer from PLN 159.02 to PLN 187.06 net per piece depending on the manufacturer (SKF). Prices are updated from supplier warehouses; larger quantities get an individual offer.
What is the delivery time for 306?
Dispatch in 2 working days from supplier warehouses in the EU. Availability is confirmed in the reply to your enquiry.
