Deep groove ball bearing 6214-RS – 70×125×24 mm

2 offers · 2 manufacturers · net prices from PLN 163.51 · dispatch in 2 working days

6214-RS is a deep groove ball bearing with a 70 mm bore, 125 mm outside diameter and 24 mm width, with one rubber contact seal (RS). The dimensions are standardised, so items from different manufacturers with the same clearance and sealing are interchangeable 1:1. All brands with current net prices are listed below.

bore d: 70 mm
outside D: 125 mm
width B: 24 mm
sealing: RS
net price from: PLN 163.51

Dimension drawing 6214-RS – one for all brands (ISO dimensions)

Main dimensions
d – bore diameter	70 mm
D – outside diameter	125 mm
B – width	24 mm
dynamic load rating C	63.7 kN (per SKF catalogue)
static load rating C₀	45 kN (per SKF catalogue)

Pictured: NSK 6214 DU. Every brand has its own product page with photo and full description.

Brands and prices 6214-RS

Net price per piece, gross incl. 23% VAT. Selected items go into one enquiry – we reply within 24 h, with better prices for larger quantities.

Brand	Manufacturer designation	Clearance	Net price	Availability
NSK	6214 DU	CN	PLN 163.51PLN 201.12 gross	supplier stockdispatch in 2 working days
SKF	6214-RS1	CN	PLN 174.42PLN 214.54 gross	supplier stockdispatch in 2 working days

Can't see your brand? Ask for an offer – we reply within 24 h.

Other versions of 6214

The same size in another design – open, shielded, tapered bore.

How manufacturers designate 6214-RS

Each brand uses its own seal and design codes. The designations below describe the same bearing.

Manufacturer	Designation	Sealing / design
NSK	6214 DU	RS – rubber contact seal, one side
SKF	6214-RS1	RS – rubber contact seal, one side

2RS, 2Z or C3 – which to choose?

2RS (two rubber seals) keeps dust and moisture out but limits speed. 2Z (metal shields) does not touch the ring, so it runs faster and cooler but protects less. 2RZ is the compromise – a non-contact seal.

Choose C3 clearance when the bearing runs hot (electric motors, fans) or with a tight shaft fit. Normal clearance CN is enough for ordinary applications.

The dimensions of 6214-RS are identical for every manufacturer, so the items in the table are interchangeable – just match the clearance and sealing.

Questions about 6214-RS

What are the dimensions of bearing 6214-RS?

Bore 70 mm, outside diameter 125 mm, width 24 mm. Standardised dimensions – the same for every manufacturer.

Are 6214-RS bearings from different brands interchangeable?

Yes. 6214 DU NSK, 6214-RS1 SKF are the same bearing under different manufacturers' designations. Match the clearance (e.g. C3) and the sealing.

How much does bearing 6214-RS cost?

At Castomer from PLN 163.51 to PLN 174.42 net per piece depending on the manufacturer (NSK, SKF). Prices are updated from supplier warehouses; larger quantities get an individual offer.

What is the delivery time for 6214-RS?

Dispatch in 2 working days from supplier warehouses in the EU. Availability is confirmed in the reply to your enquiry.
