Deep groove ball bearing 624-2RS – 4×13×5 mm
6 offers · 4 manufacturers · net prices from PLN 2.48 · dispatch in 2 working days
624-2RS is a deep groove ball bearing with a 4 mm bore, 13 mm outside diameter and 5 mm width, with two rubber contact seals (2RS) – greased for life, maintenance-free. The dimensions are standardised, so items from different manufacturers with the same clearance and sealing are interchangeable 1:1. All brands with current net prices are listed below.
- bore d
- 4 mm
- outside D
- 13 mm
- width B
- 5 mm
- sealing
- 2RS
- mass
- 0 kg
- net price from
- PLN 2.48
Brands and prices 624-2RS
Net price per piece, gross incl. 23% VAT. Selected items go into one enquiry – we reply within 24 h, with better prices for larger quantities.
| Brand | Manufacturer designation | Clearance | Net price | Availability | |
|---|---|---|---|---|---|
| ZEN | 624-2RS | CN | PLN 2.48PLN 3.05 gross | supplier stockdispatch in 2 working days | |
| NKE | 624-2RSR | CN | PLN 5.89PLN 7.24 gross | supplier stockdispatch in 2 working days | |
| NKE | 624-2RSRC3 | C3 | PLN 5.89PLN 7.24 gross | supplier stockdispatch in 2 working days | |
| KOYO | 624-2RSC3P | C3 | PLN 10.04PLN 12.35 gross | supplier stockdispatch in 2 working days | |
| SKF | 624-2RS1 | CN | PLN 10.91PLN 13.42 gross | supplier stockdispatch in 2 working days |
▸Special designs 624-2RS (1) – stainless steel, snap ring, manufacturer specials
| SKF | W624-2RS1 | CN | PLN 30.29PLN 37.26 gross | supplier stockdispatch in 2 working days |
Can't see your brand? Ask for an offer – we reply within 24 h.
Other versions of 624
The same size in another design – open, shielded, tapered bore.
How manufacturers designate 624-2RS
Each brand uses its own seal and design codes. The designations below describe the same bearing.
| Manufacturer | Designation | Sealing / design |
|---|---|---|
| NKE | 624-2RSR | 2RS – rubber contact seals, both sides |
| SKF | 624-2RS1 | 2RS – rubber contact seals, both sides |
| ZEN | 624-2RS | 2RS – rubber contact seals, both sides |
| KOYO | 624-2RSC3P | 2RS – rubber contact seals, both sides |
2RS, 2Z or C3 – which to choose?
2RS (two rubber seals) keeps dust and moisture out but limits speed. 2Z (metal shields) does not touch the ring, so it runs faster and cooler but protects less. 2RZ is the compromise – a non-contact seal.
Choose C3 clearance when the bearing runs hot (electric motors, fans) or with a tight shaft fit. Normal clearance CN is enough for ordinary applications.
The dimensions of 624-2RS are identical for every manufacturer, so the items in the table are interchangeable – just match the clearance and sealing.
Questions about 624-2RS
What are the dimensions of bearing 624-2RS?
Bore 4 mm, outside diameter 13 mm, width 5 mm. Standardised dimensions – the same for every manufacturer.
Are 624-2RS bearings from different brands interchangeable?
Yes. 624-2RSR NKE, 624-2RS1 SKF, 624-2RS ZEN, 624-2RSC3P KOYO are the same bearing under different manufacturers' designations. Match the clearance (e.g. C3) and the sealing.
How much does bearing 624-2RS cost?
At Castomer from PLN 2.48 to PLN 10.91 net per piece depending on the manufacturer (NKE, SKF, ZEN, KOYO). Prices are updated from supplier warehouses; larger quantities get an individual offer.
What is the delivery time for 624-2RS?
Dispatch in 2 working days from supplier warehouses in the EU. Availability is confirmed in the reply to your enquiry.
